| 1.0 mm Jack (Socket Contact) | ||||
|---|---|---|---|---|
| LTR | Inches (Millimeters) | |||
| Minimum | Maximum | |||
| A | .1161 | (2.95) | .1201 | (3.05) |
| B | .0937 | (2.38) | .0941 | (2.39) |
| C | .0393 | (0.997) | (.0395) | (1.003) |
| D | .063 | (1.60) | .067 | (1.70) |
| E | 0 | (0) | .002 | (0.051) |
| F | .0177 | (0.45) | .0217 | (0.55) |
| G | .158 | (4.01) | – | – |
| H | .157 HEX | (4.0 HEX) | – | – |
| J | .01697 | (0.431) | .017 | (0.437) |
| J | ||||
| Inch | (mm) | Inch | (mm) | |
| 1.0 mm Plug (Pin Contact) | ||||
|---|---|---|---|---|
| LTR | Inches (Millimeters) | |||
| Minimum | Maximum | |||
| A | .1634 | (4.15) | .1674 | (4.25) |
| B | .09340 | (2.362) | .0934 | (2.372) |
| C | .0393 | (0.997) | .0395 | (1.003) |
| D | .0496 | (1.26) | .0732 | (1.86) |
| E | .1118 | (2.84) | .1196 | (3.04) |
| F | .0118 | (0.3) | .0197 | (0.5) |
| G | .0097 | (0.247) | .0099 | (0.253) |
| H | .0170 | (0.433) | .0206 | (0.523) |
| J | 0 | (0) | .002 | (0.051) |
| K | .01697 | (0.431) | .01721 | (0.437) |
| Inch | (mm) | Inch | (mm) | |
